Model A-EWD-3810
Size 38"
Backlight LED
LCD
Type 38" color TFT active matix, wide LCD
Display Area 929.2x261.6mm
Resolution 1920x540
Contrast Ratio: 3000:1
Viewing Angles: 178（H）/178(V)
Response Time: 6.5ms
Brightness: 700nits
Aspect Ratio: 16:4.5
Interface
Input: DVI (VGA for Networking DS board)
Storage: SD / USB
Networking: RJ-45 (Option WiFi 802.11b/g / 3G)
Speaker: N/A
Functions
RTC: YES
Auto-on/off: YES
Schdule Management: Daily, Weekly, Monthly schedule setting
Remote Management Remote upload,
Remote status monitor by LAN and WLAN
Media playback: Play list, Loop, Insert
Scrollin Text: YES (Option: RSS)
Split Screen: YES
Video format: MPEG-1,MPEG-2, MPEG-4,MPEG-4.(H.264), WMV9
Picture format: JPG, JPEG, BNP, PNG, GIF
Audio format: Dolby digital, DTS, MP3, MPEG 4,WMA9
Power
Voltage: AC100-240V,50-60Hz
Consumption: 70W
"Operation Conditions
Temperature: 0 ~ 50C
Humidity: 20% ~ 90%
Dimensions
Product: 976*311*61.5mm
Package:1075*405*180mm
Weight
Net: 8KG
Gross 10KG |
